Detailed characteristics:
Color-to-color registration printing on garments and leathers such as nylon,micro-fiber twill, satin, PVC and PU,but also fitting on printing stationery, such as metal sheets,hard & soft plastic boards¡ªPVC, PP,PC,PET,EVA, APET,PETG¡ªfabric-boards,glass-plates,and ceramics etc in multi-colors.
The machine is compatible with various ink or pastes (water-based, solvent-based, silicone etc.). The number of dryer can be adjusted as needed, and UV dryer can be configured if UV inks are used.
Its streamlined design enhances energy efficiency, while the enclosed workspace ensures safety by restricting access to unauthorized personnel. An exhaust fan installed at the top instantly removes ink fumes, making it more environmentally friendly. Combining nice view, intelligence, eco-friendliness, power savings, and safety into one integrated system.
Parameter:
|
Model |
SPL |
|
Print head quantity |
Optional |
|
Print area |
500*600mm |
|
Table size |
600*900mm |
|
Max.Frame size |
700*950mm |
|
Air consumption |
0.6-0.8mpa |
|
Aircompressor |
7.5KW High pressure |
|
Air tank volume |
1-2L/m³ |
|
Squeegee size |
52mm/55mm |
|
Voltage |
380V 50Hz |
|
Total Power |
2.14KW |
|
Weight |
Ô¼600KG |
|
Machine size |
7500*1950*2000mm |
